[Kubernets] Ceph Cluster install with helm

# Default values for rook-ceph-operator
# This is a YAML-formatted file.
# Declare variables to be passed into your templates.

image:
  prefix: rook
  repository: rook/ceph
  tag: v1.8.6
  pullPolicy: IfNotPresent

crds:
  # Whether the helm chart should create and update the CRDs. If false, the CRDs must be
  # managed independently with deploy/examples/crds.yaml.
  # **WARNING** Only set during first deployment. If later disabled the cluster may be DESTROYED.
  # If the CRDs are deleted in this case, see the disaster recovery guide to restore them.
  # https://rook.github.io/docs/rook/latest/ceph-disaster-recovery.html#restoring-crds-after-deletion
  enabled: true

resources:
  limits:
    cpu: 500m
    memory: 256Mi
  requests:
    cpu: 100m
    memory: 128Mi

nodeSelector: {}
# Constraint rook-ceph-operator Deployment to nodes with label `disktype: ssd`.
# For more info, see https://kubernetes.io/docs/concepts/configuration/assign-pod-node/#nodeselector
#  disktype: ssd

# Tolerations for the rook-ceph-operator to allow it to run on nodes with particular taints
tolerations: []

# Delay to use in node.kubernetes.io/unreachable toleration
unreachableNodeTolerationSeconds: 5

# Whether rook watches its current namespace for CRDs or the entire cluster, defaults to false
currentNamespaceOnly: false

## Annotations to be added to pod
annotations: {}

## The logging level for the operator: ERROR | WARNING | INFO | DEBUG
logLevel: INFO

## If true, create & use RBAC resources
##
rbacEnable: true

## If true, create & use PSP resources
##
pspEnable: true

# Set the priority class for the rook operator deployment if desired
# priorityClassName: class

## Settings for whether to disable the drivers or other daemons if they are not
## needed
csi:
  enableRbdDriver: true
  enableCephfsDriver: true
  enableGrpcMetrics: false
  # Set to true to enable host networking for CSI CephFS and RBD nodeplugins. This may be necessary
  # in some network configurations where the SDN does not provide access to an external cluster or
  # there is significant drop in read/write performance.
  # enableCSIHostNetwork: true
  # set to false to disable deployment of snapshotter container in CephFS provisioner pod.
  enableCephfsSnapshotter: true
  # set to false to disable deployment of snapshotter container in RBD provisioner pod.
  enableRBDSnapshotter: true
  # set to false if the selinux is not enabled or unavailable in cluster nodes.
  enablePluginSelinuxHostMount : false
  # (Optional) set user created priorityclassName for csi plugin pods.
  # pluginPriorityClassName: system-node-critical

  # (Optional) set user created priorityclassName for csi provisioner pods.
  # provisionerPriorityClassName: system-cluster-critical

  # (Optional) policy for modifying a volume's ownership or permissions when the RBD PVC is being mounted.
  # supported values are documented at https://kubernetes-csi.github.io/docs/support-fsgroup.html
  rbdFSGroupPolicy: "ReadWriteOnceWithFSType"

  # (Optional) policy for modifying a volume's ownership or permissions when the CephFS PVC is being mounted.
  # supported values are documented at https://kubernetes-csi.github.io/docs/support-fsgroup.html
  cephFSFSGroupPolicy: "None"

  # OMAP generator generates the omap mapping between the PV name and the RBD image
  # which helps CSI to identify the rbd images for CSI operations.
  # CSI_ENABLE_OMAP_GENERATOR need to be enabled when we are using rbd mirroring feature.
  # By default OMAP generator is disabled and when enabled it will be deployed as a
  # sidecar with CSI provisioner pod, to enable set it to true.
  enableOMAPGenerator: false

  # Set replicas for csi provisioner deployment.
  provisionerReplicas: 2

  # Set logging level for csi containers.
  # Supported values from 0 to 5. 0 for general useful logs, 5 for trace level verbosity.
  #logLevel: 0
  # CSI CephFS plugin daemonset update strategy, supported values are OnDelete and RollingUpdate.
  # Default value is RollingUpdate.
  #rbdPluginUpdateStrategy: OnDelete
  # CSI Rbd plugin daemonset update strategy, supported values are OnDelete and RollingUpdate.
  # Default value is RollingUpdate.
  #cephFSPluginUpdateStrategy: OnDelete
  # Allow starting unsupported ceph-csi image
  allowUnsupportedVersion: false
    # (Optional) CEPH CSI RBD provisioner resource requirement list, Put here list of resource
  # requests and limits you want to apply for provisioner pod
  # csiRBDProvisionerResource: |
  #  - name : csi-provisioner
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 100m
  #      limits:
  #        memory: 256Mi
  #        cpu: 200m
  #  - name : csi-resizer
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 100m
  #      limits:
  #        memory: 256Mi
  #        cpu: 200m
  #  - name : csi-attacher
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 100m
  #      limits:
  #        memory: 256Mi
  #        cpu: 200m
  #  - name : csi-snapshotter
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 100m
  #      limits:
  #        memory: 256Mi
  #        cpu: 200m
  #  - name : csi-rbdplugin
  #    resource:
  #      requests:
  #        memory: 512Mi
  #        cpu: 250m
  #      limits:
  #        memory: 1Gi
  #        cpu: 500m
  #  - name : liveness-prometheus
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 50m
  #      limits:
  #        memory: 256Mi
  #        cpu: 100m
  # (Optional) CEPH CSI RBD plugin resource requirement list, Put here list of resource
  # requests and limits you want to apply for plugin pod
  # csiRBDPluginResource: |
  #  - name : driver-registrar
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 50m
  #      limits:
  #        memory: 256Mi
  #        cpu: 100m
  #  - name : csi-rbdplugin
  #    resource:
  #      requests:
  #        memory: 512Mi
  #        cpu: 250m
  #      limits:
  #        memory: 1Gi
  #        cpu: 500m
  #  - name : liveness-prometheus
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 50m
  #      limits:
  #        memory: 256Mi
  #        cpu: 100m
  # (Optional) CEPH CSI CephFS provisioner resource requirement list, Put here list of resource
  # requests and limits you want to apply for provisioner pod
  # csiCephFSProvisionerResource: |
  #  - name : csi-provisioner
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 100m
  #      limits:
  #        memory: 256Mi
  #        cpu: 200m
  #  - name : csi-resizer
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 100m
  #      limits:
  #        memory: 256Mi
  #        cpu: 200m
  #  - name : csi-attacher
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 100m
  #      limits:
  #        memory: 256Mi
  #        cpu: 200m
  #  - name : csi-cephfsplugin
  #    resource:
  #      requests:
  #        memory: 512Mi
  #        cpu: 250m
  #      limits:
  #        memory: 1Gi
  #        cpu: 500m
  #  - name : liveness-prometheus
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 50m
  #      limits:
  #        memory: 256Mi
  #        cpu: 100m
  # (Optional) CEPH CSI CephFS plugin resource requirement list, Put here list of resource
  # requests and limits you want to apply for plugin pod
  # csiCephFSPluginResource: |
  #  - name : driver-registrar
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 50m
  #      limits:
  #        memory: 256Mi
  #        cpu: 100m
  #  - name : csi-cephfsplugin
  #    resource:
  #      requests:
  #        memory: 512Mi
  #        cpu: 250m
  #      limits:
  #        memory: 1Gi
  #        cpu: 500m
  #  - name : liveness-prometheus
  #    resource:
  #      requests:
  #        memory: 128Mi
  #        cpu: 50m
  #      limits:
  #        memory: 256Mi
  #        cpu: 100m
  # Set provisonerTolerations and provisionerNodeAffinity for provisioner pod.
  # The CSI provisioner would be best to start on the same nodes as other ceph daemons.
  # provisionerTolerations:
  #    - key: key
  #      operator: Exists
  #      effect: NoSchedule
  # provisionerNodeAffinity: key1=value1,value2; key2=value3
  # Set pluginTolerations and pluginNodeAffinity for plugin daemonset pods.
  # The CSI plugins need to be started on all the nodes where the clients need to mount the storage.
  # pluginTolerations:
  #    - key: key
  #      operator: Exists
  #      effect: NoSchedule
  # pluginNodeAffinity: key1=value1,value2; key2=value3
  #cephfsGrpcMetricsPort: 9091
  #cephfsLivenessMetricsPort: 9081
  #rbdGrpcMetricsPort: 9090
  #csiAddonsPort: 9070
  # Enable Ceph Kernel clients on kernel < 4.17. If your kernel does not support quotas for CephFS
  # you may want to disable this setting. However, this will cause an issue during upgrades
  # with the FUSE client. See the upgrade guide: https://rook.io/docs/rook/v1.2/ceph-upgrade.html
  forceCephFSKernelClient: true
  #rbdLivenessMetricsPort: 9080
  #kubeletDirPath: /var/lib/kubelet
  #cephcsi:
    #image: quay.io/cephcsi/cephcsi:v3.5.1
  #registrar:
    #image: k8s.gcr.io/sig-storage/csi-node-driver-registrar:v2.5.0
  #provisioner:
    #image: k8s.gcr.io/sig-storage/csi-provisioner:v3.1.0
  #snapshotter:
    #image: k8s.gcr.io/sig-storage/csi-snapshotter:v5.0.1
  #attacher:
    #image: k8s.gcr.io/sig-storage/csi-attacher:v3.4.0
  #resizer:
    #image: k8s.gcr.io/sig-storage/csi-resizer:v1.4.0
  # Labels to add to the CSI CephFS Deployments and DaemonSets Pods.
  #cephfsPodLabels: "key1=value1,key2=value2"
  # Labels to add to the CSI RBD Deployments and DaemonSets Pods.
  #rbdPodLabels: "key1=value1,key2=value2"
  # Enable the volume replication controller.
  # Before enabling, ensure the Volume Replication CRDs are created.
  # See https://rook.io/docs/rook/latest/ceph-csi-drivers.html#rbd-mirroring
  volumeReplication:
    enabled: false
    #image: "quay.io/csiaddons/volumereplication-operator:v0.3.0"
  # Enable the CSIAddons sidecar.
  csiAddons:
    enabled: false
    #image: "quay.io/csiaddons/k8s-sidecar:v0.2.1"
enableDiscoveryDaemon: false
cephCommandsTimeoutSeconds: "15"

# enable the ability to have multiple Ceph filesystems in the same cluster
# WARNING: Experimental feature in Ceph Releases Octopus (v15)
# https://docs.ceph.com/en/octopus/cephfs/experimental-features/#multiple-file-systems-within-a-ceph-cluster
allowMultipleFilesystems: false

## if true, run rook operator on the host network
# useOperatorHostNetwork: true

## Rook Discover configuration
## toleration: NoSchedule, PreferNoSchedule or NoExecute
## tolerationKey: Set this to the specific key of the taint to tolerate
## tolerations: Array of tolerations in YAML format which will be added to agent deployment
## nodeAffinity: Set to labels of the node to match
# discover:
#   toleration: NoSchedule
#   tolerationKey: key
#   tolerations:
#   - key: key
#     operator: Exists
#     effect: NoSchedule
#   nodeAffinity: key1=value1,value2; key2=value3
#   podLabels: "key1=value1,key2=value2"

# In some situations SELinux relabelling breaks (times out) on large filesystems, and doesn't work with cephfs ReadWriteMany volumes (last relabel wins).
# Disable it here if you have similar issues.
# For more details see https://github.com/rook/rook/issues/2417
enableSelinuxRelabeling: true

# Writing to the hostPath is required for the Ceph mon and osd pods. Given the restricted permissions in OpenShift with SELinux,
# the pod must be running privileged in order to write to the hostPath volume, this must be set to true then.
hostpathRequiresPrivileged: false

# Disable automatic orchestration when new devices are discovered.
disableDeviceHotplug: false

# Blacklist certain disks according to the regex provided.
discoverDaemonUdev:

# imagePullSecrets option allow to pull docker images from private docker registry. Option will be passed to all service accounts.
# imagePullSecrets:
# - name: my-registry-secret

# Whether the OBC provisioner should watch on the operator namespace or not, if not the namespace of the cluster will be used
enableOBCWatchOperatorNamespace: true

admissionController:
  # Set tolerations and nodeAffinity for admission controller pod.
  # The admission controller would be best to start on the same nodes as other ceph daemons.
  # tolerations:
  #    - key: key
  #      operator: Exists
  #      effect: NoSchedule
  # nodeAffinity: key1=value1,value2; key2=value3

monitoring:
  # requires Prometheus to be pre-installed
  # enabling will also create RBAC rules to allow Operator to create ServiceMonitors
  enabled: false

# Default values for a single rook-ceph cluster
# This is a YAML-formatted file.
# Declare variables to be passed into your templates.

# Namespace of the main rook operator
operatorNamespace: rook-ceph

# The metadata.name of the CephCluster CR. The default name is the same as the namespace.
# clusterName: rook-ceph

# Ability to override the kubernetes version used in rendering the helm chart
# kubeVersion: 1.21

# Ability to override ceph.conf
# configOverride: |
#   [global]
#   mon_allow_pool_delete = true
#   osd_pool_default_size = 3
#   osd_pool_default_min_size = 2

# Installs a debugging toolbox deployment
toolbox:
  enabled: **true**
  image: rook/ceph:v1.8.6
  tolerations: []
  affinity: {}
  # Set the priority class for the toolbox if desired
  # priorityClassName: class

monitoring:
  # requires Prometheus to be pre-installed
  # enabling will also create RBAC rules to allow Operator to create ServiceMonitors
  enabled: false
  rulesNamespaceOverride:

# If true, create & use PSP resources. Set this to the same value as the rook-ceph chart.
pspEnable: true

# imagePullSecrets option allow to pull docker images from private docker registry. Option will be passed to all service accounts.
# imagePullSecrets:
# - name: my-registry-secret

# All values below are taken from the CephCluster CRD
# More information can be found at [Ceph Cluster CRD](/Documentation/ceph-cluster-crd.md)
cephClusterSpec:
  cephVersion:
    # The container image used to launch the Ceph daemon pods (mon, mgr, osd, mds, rgw).
    # v15 is octopus, and v16 is pacific.
    # RECOMMENDATION: In production, use a specific version tag instead of the general v16 flag, which pulls the latest release and could result in different
    # versions running within the cluster. See tags available at https://hub.docker.com/r/ceph/ceph/tags/.
    # If you want to be more precise, you can always use a timestamp tag such quay.io/ceph/ceph:v15.2.11-20200419
    # This tag might not contain a new Ceph version, just security fixes from the underlying operating system, which will reduce vulnerabilities
    image: quay.io/ceph/ceph:v16.2.7
    # Whether to allow unsupported versions of Ceph. Currently `octopus` and `pacific` are supported.
    # Future versions such as `pacific` would require this to be set to `true`.
    # Do not set to true in production.
    allowUnsupported: false

  # The path on the host where configuration files will be persisted. Must be specified.
  # Important: if you reinstall the cluster, make sure you delete this directory from each host or else the mons will fail to start on the new cluster.
  # In Minikube, the '/data' directory is configured to persist across reboots. Use "/data/rook" in Minikube environment.
  dataDirHostPath: /var/lib/rook

  # Whether or not upgrade should continue even if a check fails
  # This means Ceph's status could be degraded and we don't recommend upgrading but you might decide otherwise
  # Use at your OWN risk
  # To understand Rook's upgrade process of Ceph, read https://rook.io/docs/rook/latest/ceph-upgrade.html#ceph-version-upgrades
  skipUpgradeChecks: false

  # Whether or not continue if PGs are not clean during an upgrade
  continueUpgradeAfterChecksEvenIfNotHealthy: false

  # WaitTimeoutForHealthyOSDInMinutes defines the time (in minutes) the operator would wait before an OSD can be stopped for upgrade or restart.
  # If the timeout exceeds and OSD is not ok to stop, then the operator would skip upgrade for the current OSD and proceed with the next one
  # if `continueUpgradeAfterChecksEvenIfNotHealthy` is `false`. If `continueUpgradeAfterChecksEvenIfNotHealthy` is `true`, then opertor would
  # continue with the upgrade of an OSD even if its not ok to stop after the timeout. This timeout won't be applied if `skipUpgradeChecks` is `true`.
  # The default wait timeout is 10 minutes.
  waitTimeoutForHealthyOSDInMinutes: 10

  mon:
    # Set the number of mons to be started. Generally recommended to be 3.
    # For highest availability, an odd number of mons should be specified.
    count: 3
    # The mons should be on unique nodes. For production, at least 3 nodes are recommended for this reason.
    # Mons should only be allowed on the same node for test environments where data loss is acceptable.
    allowMultiplePerNode: false

  mgr:
    # When higher availability of the mgr is needed, increase the count to 2.
    # In that case, one mgr will be active and one in standby. When Ceph updates which
    # mgr is active, Rook will update the mgr services to match the active mgr.
    count: 1
    modules:
      # Several modules should not need to be included in this list. The "dashboard" and "monitoring" modules
      # are already enabled by other settings in the cluster CR.
      - name: pg_autoscaler
        enabled: true

  # enable the ceph dashboard for viewing cluster status
  dashboard:
    enabled: true
    # serve the dashboard under a subpath (useful when you are accessing the dashboard via a reverse proxy)
    # urlPrefix: /ceph-dashboard
    # serve the dashboard at the given port.
    # port: 8443
    # serve the dashboard using SSL
    ssl: true

  # Network configuration, see: https://github.com/rook/rook/blob/master/Documentation/ceph-cluster-crd.md#network-configuration-settings
  # network:
  #   # enable host networking
  #   provider: host
  #   # EXPERIMENTAL: enable the Multus network provider
  #   provider: multus
  #   selectors:
  #     # The selector keys are required to be `public` and `cluster`.
  #     # Based on the configuration, the operator will do the following:
  #     #   1. if only the `public` selector key is specified both public_network and cluster_network Ceph settings will listen on that interface
  #     #   2. if both `public` and `cluster` selector keys are specified the first one will point to 'public_network' flag and the second one to 'cluster_network'
  #     #
  #     # In order to work, each selector value must match a NetworkAttachmentDefinition object in Multus
  #     #
  #     # public: public-conf --> NetworkAttachmentDefinition object name in Multus
  #     # cluster: cluster-conf --> NetworkAttachmentDefinition object name in Multus
  #   # Provide internet protocol version. IPv6, IPv4 or empty string are valid options. Empty string would mean IPv4
  #   ipFamily: "IPv6"
  #   # Ceph daemons to listen on both IPv4 and Ipv6 networks
  #   dualStack: false

  # enable the crash collector for ceph daemon crash collection
  crashCollector:
    disable: false
    # Uncomment daysToRetain to prune ceph crash entries older than the
    # specified number of days.
    # daysToRetain: 30

  # enable log collector, daemons will log on files and rotate
  # logCollector:
  #   enabled: true
  #   periodicity: 24h # SUFFIX may be 'h' for hours or 'd' for days.

  # automate [data cleanup process](https://github.com/rook/rook/blob/master/Documentation/ceph-teardown.md#delete-the-data-on-hosts) in cluster destruction.
  cleanupPolicy:
    # Since cluster cleanup is destructive to data, confirmation is required.
    # To destroy all Rook data on hosts during uninstall, confirmation must be set to "yes-really-destroy-data".
    # This value should only be set when the cluster is about to be deleted. After the confirmation is set,
    # Rook will immediately stop configuring the cluster and only wait for the delete command.
    # If the empty string is set, Rook will not destroy any data on hosts during uninstall.
    confirmation: ""
    # sanitizeDisks represents settings for sanitizing OSD disks on cluster deletion
    sanitizeDisks:
      # method indicates if the entire disk should be sanitized or simply ceph's metadata
      # in both case, re-install is possible
      # possible choices are 'complete' or 'quick' (default)
      method: quick
      # dataSource indicate where to get random bytes from to write on the disk
      # possible choices are 'zero' (default) or 'random'
      # using random sources will consume entropy from the system and will take much more time then the zero source
      dataSource: zero
      # iteration overwrite N times instead of the default (1)
      # takes an integer value
      iteration: 1
    # allowUninstallWithVolumes defines how the uninstall should be performed
    # If set to true, cephCluster deletion does not wait for the PVs to be deleted.
    allowUninstallWithVolumes: false

  # To control where various services will be scheduled by kubernetes, use the placement configuration sections below.
  # The example under 'all' would have all services scheduled on kubernetes nodes labeled with 'role=storage-node' and
  # tolerate taints with a key of 'storage-node'.
  # placement:
  #   all:
  #     nodeAffinity:
  #       requiredDuringSchedulingIgnoredDuringExecution:
  #         nodeSelectorTerms:
  #           - matchExpressions:
  #             - key: role
  #               operator: In
  #             values:
  #             - storage-node
  #     podAffinity:
  #     podAntiAffinity:
  #     topologySpreadConstraints:
  #     tolerations:
  #     - key: storage-node
  #       operator: Exists
  #   # The above placement information can also be specified for mon, osd, and mgr components
  #   mon:
  #   # Monitor deployments may contain an anti-affinity rule for avoiding monitor
  #   # collocation on the same node. This is a required rule when host network is used
  #   # or when AllowMultiplePerNode is false. Otherwise this anti-affinity rule is a
  #   # preferred rule with weight: 50.
  #   osd:
  #   mgr:
  #   cleanup:

  # annotations:
  #   all:
  #   mon:
  #   osd:
  #   cleanup:
  #   prepareosd:
  #   # If no mgr annotations are set, prometheus scrape annotations will be set by default.
  #   mgr:

  # labels:
  #   all:
  #   mon:
  #   osd:
  #   cleanup:
  #   mgr:
  #   prepareosd:
  #   # monitoring is a list of key-value pairs. It is injected into all the monitoring resources created by operator.
  #   # These labels can be passed as LabelSelector to Prometheus
  #   monitoring:

  # resources:
  #   # The requests and limits set here, allow the mgr pod to use half of one CPU core and 1 gigabyte of memory
  #   mgr:
  #     limits:
  #       cpu: "500m"
  #       memory: "1024Mi"
  #     requests:
  #       cpu: "500m"
  #       memory: "1024Mi"
  #   # The above example requests/limits can also be added to the other components
  #   mon:
  #   osd:
  #   prepareosd:
  #   mgr-sidecar:
  #   crashcollector:
  #   logcollector:
  #   cleanup:

  # The option to automatically remove OSDs that are out and are safe to destroy.
  removeOSDsIfOutAndSafeToRemove: false

  # priority classes to apply to ceph resources
  # priorityClassNames:
  #   all: rook-ceph-default-priority-class
  #   mon: rook-ceph-mon-priority-class
  #   osd: rook-ceph-osd-priority-class
  #   mgr: rook-ceph-mgr-priority-class
  #   crashcollector: rook-ceph-crashcollector-priority-class

  storage: # cluster level storage configuration and selection
    useAllNodes: true
    useAllDevices: true
    # deviceFilter:
    # config:
    #   crushRoot: "custom-root" # specify a non-default root label for the CRUSH map
    #   metadataDevice: "md0" # specify a non-rotational storage so ceph-volume will use it as block db device of bluestore.
    #   databaseSizeMB: "1024" # uncomment if the disks are smaller than 100 GB
    #   journalSizeMB: "1024"  # uncomment if the disks are 20 GB or smaller
    #   osdsPerDevice: "1" # this value can be overridden at the node or device level
    #   encryptedDevice: "true" # the default value for this option is "false"
    # # Individual nodes and their config can be specified as well, but 'useAllNodes' above must be set to false. Then, only the named
    # # nodes below will be used as storage resources.  Each node's 'name' field should match their 'kubernetes.io/hostname' label.
    # nodes:
    #   - name: "172.17.4.201"
    #     devices: # specific devices to use for storage can be specified for each node
    #       - name: "sdb"
    #       - name: "nvme01" # multiple osds can be created on high performance devices
    #         config:
    #           osdsPerDevice: "5"
    #       - name: "/dev/disk/by-id/ata-ST4000DM004-XXXX" # devices can be specified using full udev paths
    #     config: # configuration can be specified at the node level which overrides the cluster level config
    #   - name: "172.17.4.301"
    #     deviceFilter: "^sd."

  # The section for configuring management of daemon disruptions during upgrade or fencing.
  disruptionManagement:
    # If true, the operator will create and manage PodDisruptionBudgets for OSD, Mon, RGW, and MDS daemons. OSD PDBs are managed dynamically
    # via the strategy outlined in the [design](https://github.com/rook/rook/blob/master/design/ceph/ceph-managed-disruptionbudgets.md). The operator will
    # block eviction of OSDs by default and unblock them safely when drains are detected.
    managePodBudgets: true
    # A duration in minutes that determines how long an entire failureDomain like `region/zone/host` will be held in `noout` (in addition to the
    # default DOWN/OUT interval) when it is draining. This is only relevant when  `managePodBudgets` is `true`. The default value is `30` minutes.
    osdMaintenanceTimeout: 30
    # A duration in minutes that the operator will wait for the placement groups to become healthy (active+clean) after a drain was completed and OSDs came back up.
    # Operator will continue with the next drain if the timeout exceeds. It only works if `managePodBudgets` is `true`.
    # No values or 0 means that the operator will wait until the placement groups are healthy before unblocking the next drain.
    pgHealthCheckTimeout: 0
    # If true, the operator will create and manage MachineDisruptionBudgets to ensure OSDs are only fenced when the cluster is healthy.
    # Only available on OpenShift.
    manageMachineDisruptionBudgets: false
    # Namespace in which to watch for the MachineDisruptionBudgets.
    machineDisruptionBudgetNamespace: openshift-machine-api

  # Configure the healthcheck and liveness probes for ceph pods.
  # Valid values for daemons are 'mon', 'osd', 'status'
  healthCheck:
    daemonHealth:
      mon:
        disabled: false
        interval: 45s
      osd:
        disabled: false
        interval: 60s
      status:
        disabled: false
        interval: 60s
    # Change pod liveness probe, it works for all mon, mgr, and osd pods.
    livenessProbe:
      mon:
        disabled: false
      mgr:
        disabled: false
      osd:
        disabled: false

ingress:
  dashboard: {}
    # annotations:
    #   kubernetes.io/ingress.class: nginx
    #   external-dns.alpha.kubernetes.io/hostname: example.com
    #   nginx.ingress.kubernetes.io/rewrite-target: /ceph-dashboard/$2
    # host:
    #   name: example.com
    #   path: "/ceph-dashboard(/|$)(.*)"
    # tls:

cephBlockPools:
  - name: ceph-blockpool
    # see https://github.com/rook/rook/blob/master/Documentation/ceph-pool-crd.md#spec for available configuration
    spec:
      failureDomain: host
      replicated:
        size: 3
    storageClass:
      enabled: true
      name: ceph-block
      isDefault: true
      reclaimPolicy: Delete
      allowVolumeExpansion: true
      mountOptions: []
      # see https://github.com/rook/rook/blob/master/Documentation/ceph-block.md#provision-storage for available configuration
      parameters:
        # (optional) mapOptions is a comma-separated list of map options.
        # For krbd options refer
        # https://docs.ceph.com/docs/master/man/8/rbd/#kernel-rbd-krbd-options
        # For nbd options refer
        # https://docs.ceph.com/docs/master/man/8/rbd-nbd/#options
        # mapOptions: lock_on_read,queue_depth=1024

        # (optional) unmapOptions is a comma-separated list of unmap options.
        # For krbd options refer
        # https://docs.ceph.com/docs/master/man/8/rbd/#kernel-rbd-krbd-options
        # For nbd options refer
        # https://docs.ceph.com/docs/master/man/8/rbd-nbd/#options
        # unmapOptions: force

        # RBD image format. Defaults to "2".
        imageFormat: "2"
        # RBD image features. Available for imageFormat: "2". CSI RBD currently supports only `layering` feature.
        imageFeatures: layering
        # The secrets contain Ceph admin credentials.
        csi.storage.k8s.io/provisioner-secret-name: rook-csi-rbd-provisioner
        csi.storage.k8s.io/provisioner-secret-namespace: rook-ceph
        csi.storage.k8s.io/controller-expand-secret-name: rook-csi-rbd-provisioner
        csi.storage.k8s.io/controller-expand-secret-namespace: rook-ceph
        csi.storage.k8s.io/node-stage-secret-name: rook-csi-rbd-node
        csi.storage.k8s.io/node-stage-secret-namespace: rook-ceph
        # Specify the filesystem type of the volume. If not specified, csi-provisioner
        # will set default as `ext4`. Note that `xfs` is not recommended due to potential deadlock
        # in hyperconverged settings where the volume is mounted on the same node as the osds.
        csi.storage.k8s.io/fstype: ext4

cephFileSystems:
  - name: ceph-filesystem
    # see https://github.com/rook/rook/blob/master/Documentation/ceph-filesystem-crd.md#filesystem-settings for available configuration
    spec:
      metadataPool:
        replicated:
          size: 3
      dataPools:
        - failureDomain: host
          replicated:
            size: 3
      metadataServer:
        activeCount: 1
        activeStandby: true
    storageClass:
      enabled: true
      isDefault: false
      name: ceph-filesystem
      reclaimPolicy: Delete
      allowVolumeExpansion: true
      mountOptions: []
      # see https://github.com/rook/rook/blob/master/Documentation/ceph-filesystem.md#provision-storage for available configuration
      parameters:
        # The secrets contain Ceph admin credentials.
        csi.storage.k8s.io/provisioner-secret-name: rook-csi-cephfs-provisioner
        csi.storage.k8s.io/provisioner-secret-namespace: rook-ceph
        csi.storage.k8s.io/controller-expand-secret-name: rook-csi-cephfs-provisioner
        csi.storage.k8s.io/controller-expand-secret-namespace: rook-ceph
        csi.storage.k8s.io/node-stage-secret-name: rook-csi-cephfs-node
        csi.storage.k8s.io/node-stage-secret-namespace: rook-ceph
        # Specify the filesystem type of the volume. If not specified, csi-provisioner
        # will set default as `ext4`. Note that `xfs` is not recommended due to potential deadlock
        # in hyperconverged settings where the volume is mounted on the same node as the osds.
        csi.storage.k8s.io/fstype: ext4

cephFileSystemVolumeSnapshotClass:
  enabled: false
  name: ceph-filesystem
  isDefault: true
  deletionPolicy: Delete
  annotations: {}
  labels: {}
  # see https://rook.io/docs/rook/latest/ceph-csi-snapshot.html#cephfs-snapshots for available configuration
  parameters: {}

cephBlockPoolsVolumeSnapshotClass:
  enabled: false
  name: ceph-block
  isDefault: false
  deletionPolicy: Delete
  annotations: {}
  labels: {}
  # see https://rook.io/docs/rook/latest/ceph-csi-snapshot.html#rbd-snapshots for available configuration
  parameters: {}

cephObjectStores:
  - name: ceph-objectstore
    # see https://github.com/rook/rook/blob/master/Documentation/ceph-object-store-crd.md#object-store-settings for available configuration
    spec:
      metadataPool:
        failureDomain: host
        replicated:
          size: 3
      dataPool:
        failureDomain: host
        erasureCoded:
          dataChunks: 2
          codingChunks: 1
      preservePoolsOnDelete: true
      gateway:
        port: 80
        # securePort: 443
        # sslCertificateRef:
        instances: 1
      healthCheck:
        bucket:
          interval: 60s
    storageClass:
      enabled: true
      name: ceph-bucket
      reclaimPolicy: Delete
      # see https://github.com/rook/rook/blob/master/Documentation/ceph-object-bucket-claim.md#storageclass for available configuration
      parameters:
        # note: objectStoreNamespace and objectStoreName are configured by the chart
        region: ap-northeast-2

$ helm install --create-namespace --namespace rook-ceph .

(base) joonwookim@Joonwooui-MacBookPro ~ % kubectl --namespace rook-ceph logs -f -l "app=rook-ceph-operator"
2022-03-05 02:03:36.224200 I | op-bucket-prov: ceph bucket provisioner launched watching for provisioner "rook-ceph.ceph.rook.io/bucket"
2022-03-05 02:03:36.226129 I | op-bucket-prov: successfully reconciled bucket provisioner
I0305 02:03:36.226216       1 manager.go:135] objectbucket.io/provisioner-manager "msg"="starting provisioner"  "name"="rook-ceph.ceph.rook.io/bucket"
2022-03-05 02:03:36.442504 I | op-k8sutil: CSI_RBD_FSGROUPPOLICY="ReadWriteOnceWithFSType" (configmap)
2022-03-05 02:03:36.453278 I | ceph-csi: CSIDriver object updated for driver "rook-ceph.rbd.csi.ceph.com"
2022-03-05 02:03:36.453330 I | op-k8sutil: CSI_CEPHFS_FSGROUPPOLICY="None" (configmap)
2022-03-05 02:03:36.462147 I | ceph-csi: CSIDriver object updated for driver "rook-ceph.cephfs.csi.ceph.com"
2022-03-05 02:03:51.747049 E | clusterdisruption-controller: failed to check cluster health: failed to get status. . timed out: exit status 1
2022-03-05 02:03:55.839715 I | op-mon: mons running: [a]
2022-03-05 02:04:07.027358 E | clusterdisruption-controller: failed to check cluster health: failed to get status. . timed out: exit status 1
2022-03-05 02:04:16.146028 I | op-mon: mons running: [a]
2022-03-05 02:04:22.437825 E | clusterdisruption-controller: failed to check cluster health: failed to get status. . timed out: exit status 1
2022-03-05 02:04:25.750236 I | op-mon: Monitors in quorum: [a]
2022-03-05 02:04:25.750272 I | op-mon: mons created: 1
2022-03-05 02:04:26.528449 I | clusterdisruption-controller: all PGs are active+clean. Restoring default OSD pdb settings
2022-03-05 02:04:26.528488 I | clusterdisruption-controller: creating the default pdb "rook-ceph-osd" with maxUnavailable=1 for all osd
2022-03-05 02:04:26.546093 I | clusterdisruption-controller: reconciling osd pdb reconciler as the allowed disruptions in default pdb is 0
2022-03-05 02:04:27.640106 I | op-mon: waiting for mon quorum with [a]
2022-03-05 02:04:27.655392 I | op-mon: mons running: [a]
2022-03-05 02:04:28.425217 I | clusterdisruption-controller: reconciling osd pdb reconciler as the allowed disruptions in default pdb is 0
2022-03-05 02:04:29.530958 I | op-mon: Monitors in quorum: [a]
2022-03-05 02:04:29.531001 I | op-config: setting "global"="mon allow pool delete"="true" option to the mon configuration database
2022-03-05 02:04:30.254069 I | clusterdisruption-controller: reconciling osd pdb reconciler as the allowed disruptions in default pdb is 0
2022-03-05 02:04:30.656369 I | op-config: successfully set "global"="mon allow pool delete"="true" option to the mon configuration database
2022-03-05 02:04:30.656420 I | op-config: setting "global"="mon cluster log file"="" option to the mon configuration database
2022-03-05 02:04:31.425251 I | op-config: successfully set "global"="mon cluster log file"="" option to the mon configuration database
2022-03-05 02:04:31.425291 I | op-config: setting "global"="mon allow pool size one"="true" option to the mon configuration database
2022-03-05 02:04:32.064917 I | op-config: successfully set "global"="mon allow pool size one"="true" option to the mon configuration database
2022-03-05 02:04:32.064953 I | op-config: setting "global"="osd scrub auto repair"="true" option to the mon configuration database
2022-03-05 02:04:32.758480 I | op-config: successfully set "global"="osd scrub auto repair"="true" option to the mon configuration database
2022-03-05 02:04:32.758526 I | op-config: setting "global"="log to file"="false" option to the mon configuration database
2022-03-05 02:04:33.458363 I | op-config: successfully set "global"="log to file"="false" option to the mon configuration database
2022-03-05 02:04:33.458393 I | op-config: setting "global"="rbd_default_features"="3" option to the mon configuration database
2022-03-05 02:04:34.145570 I | op-config: successfully set "global"="rbd_default_features"="3" option to the mon configuration database
2022-03-05 02:04:34.145610 I | op-config: deleting "log file" option from the mon configuration database
2022-03-05 02:04:34.839478 I | op-config: successfully deleted "log file" option from the mon configuration database
2022-03-05 02:04:34.839518 I | op-mon: creating mon b
2022-03-05 02:04:34.892213 I | op-mon: mon "a" endpoint is [v2:10.105.8.75:3300,v1:10.105.8.75:6789]
2022-03-05 02:04:34.915903 I | op-mon: mon "b" endpoint is [v2:10.109.89.77:3300,v1:10.109.89.77:6789]
2022-03-05 02:04:34.935815 I | op-mon: saved mon endpoints to config map map[csi-cluster-config-json:[{"clusterID":"rook-ceph","monitors":["10.105.8.75:6789","10.109.89.77:6789"]}] data:a=10.105.8.75:6789,b=10.109.89.77:6789 mapping:{"node":{"a":{"Name":"k5","Hostname":"k5","Address":"10.0.0.15"},"b":{"Name":"k6","Hostname":"k6","Address":"10.0.0.16"},"c":{"Name":"k4","Hostname":"k4","Address":"10.0.0.14"}}} maxMonId:0]
2022-03-05 02:04:35.044972 I | cephclient: writing config file /var/lib/rook/rook-ceph/rook-ceph.config
2022-03-05 02:04:35.045270 I | cephclient: generated admin config in /var/lib/rook/rook-ceph
2022-03-05 02:04:35.457913 I | op-mon: 1 of 2 expected mon deployments exist. creating new deployment(s).
2022-03-05 02:04:35.465518 I | op-mon: deployment for mon rook-ceph-mon-a already exists. updating if needed
2022-03-05 02:04:35.489264 I | op-k8sutil: deployment "rook-ceph-mon-a" did not change, nothing to update
2022-03-05 02:04:35.643588 I | op-mon: updating maxMonID from 0 to 1 after committing mon "b"
2022-03-05 02:04:36.446549 I | op-mon: saved mon endpoints to config map map[csi-cluster-config-json:[{"clusterID":"rook-ceph","monitors":["10.105.8.75:6789","10.109.89.77:6789"]}] data:a=10.105.8.75:6789,b=10.109.89.77:6789 mapping:{"node":{"a":{"Name":"k5","Hostname":"k5","Address":"10.0.0.15"},"b":{"Name":"k6","Hostname":"k6","Address":"10.0.0.16"},"c":{"Name":"k4","Hostname":"k4","Address":"10.0.0.14"}}} maxMonId:1]
2022-03-05 02:04:36.446595 I | op-mon: waiting for mon quorum with [a b]
2022-03-05 02:04:36.850374 I | op-mon: mon b is not yet running
2022-03-05 02:04:36.850411 I | op-mon: mons running: [a]
2022-03-05 02:04:37.533440 I | op-mon: Monitors in quorum: [a]
2022-03-05 02:04:37.533483 I | op-mon: mons created: 2
2022-03-05 02:04:38.223093 I | op-mon: waiting for mon quorum with [a b]
2022-03-05 02:04:38.245327 I | op-mon: mon b is not yet running
2022-03-05 02:04:38.245385 I | op-mon: mons running: [a]
2022-03-05 02:04:43.265041 I | op-mon: mons running: [a b]
2022-03-05 02:04:44.057019 I | op-mon: Monitors in quorum: [a b]
2022-03-05 02:04:44.057066 I | op-config: setting "global"="mon allow pool delete"="true" option to the mon configuration database
2022-03-05 02:04:44.748623 I | op-config: successfully set "global"="mon allow pool delete"="true" option to the mon configuration database
2022-03-05 02:04:44.748666 I | op-config: setting "global"="mon cluster log file"="" option to the mon configuration database
2022-03-05 02:04:45.436895 I | op-config: successfully set "global"="mon cluster log file"="" option to the mon configuration database
2022-03-05 02:04:45.436936 I | op-config: setting "global"="mon allow pool size one"="true" option to the mon configuration database
2022-03-05 02:04:46.155629 I | op-config: successfully set "global"="mon allow pool size one"="true" option to the mon configuration database
2022-03-05 02:04:46.155660 I | op-config: setting "global"="osd scrub auto repair"="true" option to the mon configuration database
2022-03-05 02:04:46.858778 I | op-config: successfully set "global"="osd scrub auto repair"="true" option to the mon configuration database
2022-03-05 02:04:46.858811 I | op-config: setting "global"="log to file"="false" option to the mon configuration database
2022-03-05 02:04:47.543798 I | op-config: successfully set "global"="log to file"="false" option to the mon configuration database
2022-03-05 02:04:47.543836 I | op-config: setting "global"="rbd_default_features"="3" option to the mon configuration database
2022-03-05 02:04:48.228725 I | op-config: successfully set "global"="rbd_default_features"="3" option to the mon configuration database
2022-03-05 02:04:48.228764 I | op-config: deleting "log file" option from the mon configuration database
2022-03-05 02:04:48.938314 I | op-config: successfully deleted "log file" option from the mon configuration database
2022-03-05 02:04:48.938355 I | op-mon: creating mon c
2022-03-05 02:04:48.986666 I | op-mon: mon "a" endpoint is [v2:10.105.8.75:3300,v1:10.105.8.75:6789]
2022-03-05 02:04:49.031265 I | op-mon: mon "b" endpoint is [v2:10.109.89.77:3300,v1:10.109.89.77:6789]
2022-03-05 02:04:49.051489 I | op-mon: mon "c" endpoint is [v2:10.103.231.110:3300,v1:10.103.231.110:6789]
2022-03-05 02:04:49.346160 I | op-mon: saved mon endpoints to config map map[csi-cluster-config-json:[{"clusterID":"rook-ceph","monitors":["10.105.8.75:6789","10.109.89.77:6789","10.103.231.110:6789"]}] data:a=10.105.8.75:6789,b=10.109.89.77:6789,c=10.103.231.110:6789 mapping:{"node":{"a":{"Name":"k5","Hostname":"k5","Address":"10.0.0.15"},"b":{"Name":"k6","Hostname":"k6","Address":"10.0.0.16"},"c":{"Name":"k4","Hostname":"k4","Address":"10.0.0.14"}}} maxMonId:1]
2022-03-05 02:04:49.944432 I | cephclient: writing config file /var/lib/rook/rook-ceph/rook-ceph.config
2022-03-05 02:04:49.944715 I | cephclient: generated admin config in /var/lib/rook/rook-ceph
2022-03-05 02:04:50.356582 I | op-mon: 2 of 3 expected mon deployments exist. creating new deployment(s).
2022-03-05 02:04:50.364613 I | op-mon: deployment for mon rook-ceph-mon-a already exists. updating if needed
2022-03-05 02:04:50.379820 I | op-k8sutil: deployment "rook-ceph-mon-a" did not change, nothing to update
2022-03-05 02:04:50.387627 I | op-mon: deployment for mon rook-ceph-mon-b already exists. updating if needed
2022-03-05 02:04:50.400406 I | op-k8sutil: deployment "rook-ceph-mon-b" did not change, nothing to update
2022-03-05 02:04:50.544151 I | op-mon: updating maxMonID from 1 to 2 after committing mon "c"
2022-03-05 02:04:51.346693 I | op-mon: saved mon endpoints to config map map[csi-cluster-config-json:[{"clusterID":"rook-ceph","monitors":["10.105.8.75:6789","10.109.89.77:6789","10.103.231.110:6789"]}] data:c=10.103.231.110:6789,a=10.105.8.75:6789,b=10.109.89.77:6789 mapping:{"node":{"a":{"Name":"k5","Hostname":"k5","Address":"10.0.0.15"},"b":{"Name":"k6","Hostname":"k6","Address":"10.0.0.16"},"c":{"Name":"k4","Hostname":"k4","Address":"10.0.0.14"}}} maxMonId:2]
2022-03-05 02:04:51.346730 I | op-mon: waiting for mon quorum with [a b c]
2022-03-05 02:04:51.949645 I | op-mon: mon c is not yet running
2022-03-05 02:04:51.949687 I | op-mon: mons running: [a b]
2022-03-05 02:04:52.571493 I | op-mon: Monitors in quorum: [a b]
2022-03-05 02:04:52.571523 I | op-mon: mons created: 3
2022-03-05 02:04:53.323326 I | op-mon: waiting for mon quorum with [a b c]
2022-03-05 02:04:53.362450 I | op-mon: mon c is not yet running
2022-03-05 02:04:53.368565 I | op-mon: mons running: [a b]
2022-03-05 02:04:58.402415 I | op-mon: mons running: [a b c]
2022-03-05 02:04:59.062050 I | op-mon: Monitors in quorum: [a b c]
2022-03-05 02:04:59.062086 I | op-config: setting "global"="mon allow pool delete"="true" option to the mon configuration database
2022-03-05 02:04:59.768068 I | op-config: successfully set "global"="mon allow pool delete"="true" option to the mon configuration database
2022-03-05 02:04:59.768123 I | op-config: setting "global"="mon cluster log file"="" option to the mon configuration database
2022-03-05 02:05:00.953350 I | clusterdisruption-controller: reconciling osd pdb reconciler as the allowed disruptions in default pdb is 0
2022-03-05 02:05:01.340878 I | op-config: successfully set "global"="mon cluster log file"="" option to the mon configuration database
2022-03-05 02:05:01.340905 I | op-config: setting "global"="mon allow pool size one"="true" option to the mon configuration database
2022-03-05 02:05:02.770751 I | clusterdisruption-controller: reconciling osd pdb reconciler as the allowed disruptions in default pdb is 0
2022-03-05 02:05:02.962750 I | op-config: successfully set "global"="mon allow pool size one"="true" option to the mon configuration database
2022-03-05 02:05:02.962779 I | op-config: setting "global"="osd scrub auto repair"="true" option to the mon configuration database
2022-03-05 02:05:03.633404 I | op-config: successfully set "global"="osd scrub auto repair"="true" option to the mon configuration database
2022-03-05 02:05:03.633450 I | op-config: setting "global"="log to file"="false" option to the mon configuration database
2022-03-05 02:05:04.329027 I | op-config: successfully set "global"="log to file"="false" option to the mon configuration database
2022-03-05 02:05:04.329074 I | op-config: setting "global"="rbd_default_features"="3" option to the mon configuration database
2022-03-05 02:05:04.973527 I | op-config: successfully set "global"="rbd_default_features"="3" option to the mon configuration database
2022-03-05 02:05:04.973561 I | op-config: deleting "log file" option from the mon configuration database
2022-03-05 02:05:05.756922 I | op-config: successfully deleted "log file" option from the mon configuration database
2022-03-05 02:05:05.770940 I | cephclient: getting or creating ceph auth key "client.csi-rbd-provisioner"
2022-03-05 02:05:06.536921 I | cephclient: getting or creating ceph auth key "client.csi-rbd-node"
2022-03-05 02:05:07.268267 I | cephclient: getting or creating ceph auth key "client.csi-cephfs-provisioner"
2022-03-05 02:05:07.972069 I | cephclient: getting or creating ceph auth key "client.csi-cephfs-node"
2022-03-05 02:05:08.749672 I | ceph-csi: created kubernetes csi secrets for cluster "rook-ceph"
2022-03-05 02:05:08.749705 I | cephclient: getting or creating ceph auth key "client.crash"
2022-03-05 02:05:09.448025 I | ceph-crashcollector-controller: created kubernetes crash collector secret for cluster "rook-ceph"
2022-03-05 02:05:10.155293 I | cephclient: successfully enabled msgr2 protocol
2022-03-05 02:05:10.155335 I | op-config: deleting "mon_mds_skip_sanity" option from the mon configuration database
2022-03-05 02:05:10.852449 I | op-config: successfully deleted "mon_mds_skip_sanity" option from the mon configuration database
2022-03-05 02:05:10.852476 I | cephclient: create rbd-mirror bootstrap peer token "client.rbd-mirror-peer"
2022-03-05 02:05:10.852486 I | cephclient: getting or creating ceph auth key "client.rbd-mirror-peer"
2022-03-05 02:05:11.569679 I | cephclient: successfully created rbd-mirror bootstrap peer token for cluster "rook-ceph"
2022-03-05 02:05:11.598314 I | op-mgr: start running mgr
2022-03-05 02:05:11.598358 I | cephclient: getting or creating ceph auth key "mgr.a"
2022-03-05 02:05:12.537505 E | ceph-crashcollector-controller: node reconcile failed on op "unchanged": Operation cannot be fulfilled on deployments.apps "rook-ceph-crashcollector-k5": the object has been modified; please apply your changes to the latest version and try again
2022-03-05 02:05:20.540161 E | ceph-crashcollector-controller: node reconcile failed on op "unchanged": Operation cannot be fulfilled on deployments.apps "rook-ceph-crashcollector-k4": the object has been modified; please apply your changes to the latest version and try again
2022-03-05 02:05:20.562298 E | ceph-crashcollector-controller: node reconcile failed on op "unchanged": Operation cannot be fulfilled on deployments.apps "rook-ceph-crashcollector-k4": the object has been modified; please apply your changes to the latest version and try again
2022-03-05 02:05:32.259333 I | clusterdisruption-controller: reconciling osd pdb reconciler as the allowed disruptions in default pdb is 0
2022-03-05 02:05:33.423600 I | op-k8sutil: finished waiting for updated deployment "rook-ceph-mgr-a"
2022-03-05 02:05:33.431505 I | op-mgr: setting services to point to mgr "a"
2022-03-05 02:05:33.524526 I | op-mgr: no need to update service "rook-ceph-mgr"
2022-03-05 02:05:33.524652 I | op-mgr: no need to update service "rook-ceph-mgr-dashboard"
2022-03-05 02:05:33.525206 I | op-mgr: successful modules: balancer
2022-03-05 02:05:33.624040 I | op-osd: start running osds in namespace "rook-ceph"
2022-03-05 02:05:33.624230 I | op-osd: wait timeout for healthy OSDs during upgrade or restart is "10m0s"
2022-03-05 02:05:33.632471 I | op-osd: start provisioning the OSDs on PVCs, if needed
2022-03-05 02:05:33.638091 I | op-osd: no storageClassDeviceSets defined to configure OSDs on PVCs
2022-03-05 02:05:33.638120 I | op-osd: start provisioning the OSDs on nodes, if needed
2022-03-05 02:05:33.830344 I | op-osd: 3 of the 6 storage nodes are valid
2022-03-05 02:05:34.025311 I | op-osd: started OSD provisioning job for node "k4"
2022-03-05 02:05:34.224768 I | op-osd: started OSD provisioning job for node "k5"
2022-03-05 02:05:34.424518 I | op-osd: started OSD provisioning job for node "k6"
2022-03-05 02:05:34.430623 I | op-osd: OSD orchestration status for node k4 is "starting"
2022-03-05 02:05:34.430669 I | op-osd: OSD orchestration status for node k5 is "starting"
2022-03-05 02:05:34.430692 I | op-osd: OSD orchestration status for node k6 is "starting"
2022-03-05 02:05:35.724001 I | op-osd: OSD orchestration status for node k4 is "orchestrating"
2022-03-05 02:05:36.159281 I | op-osd: OSD orchestration status for node k5 is "orchestrating"
2022-03-05 02:05:36.425393 I | clusterdisruption-controller: reconciling osd pdb reconciler as the allowed disruptions in default pdb is 0
2022-03-05 02:05:36.732159 I | op-osd: OSD orchestration status for node k6 is "orchestrating"
2022-03-05 02:05:40.842188 I | op-mgr: successful modules: prometheus
2022-03-05 02:05:40.847402 I | op-config: setting "global"="osd_pool_default_pg_autoscale_mode"="on" option to the mon configuration database
2022-03-05 02:05:42.429980 I | op-config: successfully set "global"="osd_pool_default_pg_autoscale_mode"="on" option to the mon configuration database
2022-03-05 02:05:42.430010 I | op-config: setting "global"="mon_pg_warn_min_per_osd"="0" option to the mon configuration database
2022-03-05 02:05:43.865620 I | op-config: successfully set "global"="mon_pg_warn_min_per_osd"="0" option to the mon configuration database
2022-03-05 02:05:43.865652 I | op-mgr: successful modules: mgr module(s) from the spec
2022-03-05 02:05:45.781344 I | op-osd: OSD orchestration status for node k4 is "completed"
2022-03-05 02:05:45.781375 I | op-osd: creating OSD 0 on node "k4"
2022-03-05 02:05:45.934991 I | clusterdisruption-controller: osd "rook-ceph-osd-0" is down but no node drain is detected
2022-03-05 02:05:46.823329 I | op-osd: OSD orchestration status for node k5 is "completed"
2022-03-05 02:05:46.823360 I | op-osd: creating OSD 2 on node "k5"
2022-03-05 02:05:46.923939 I | op-osd: OSD orchestration status for node k6 is "completed"
2022-03-05 02:05:46.923972 I | op-osd: creating OSD 1 on node "k6"
2022-03-05 02:05:47.124479 E | ceph-crashcollector-controller: node reconcile failed on op "unchanged": Operation cannot be fulfilled on deployments.apps "rook-ceph-crashcollector-k5": the object has been modified; please apply your changes to the latest version and try again
2022-03-05 02:05:51.031679 I | clusterdisruption-controller: osd is down in the failure domain "k4", but pgs are active+clean. Requeuing in case pg status is not updated yet...
2022-03-05 02:05:51.037914 I | clusterdisruption-controller: osd "rook-ceph-osd-1" is down but no node drain is detected
2022-03-05 02:05:51.038095 I | clusterdisruption-controller: osd "rook-ceph-osd-2" is down but no node drain is detected
2022-03-05 02:05:51.038206 I | clusterdisruption-controller: osd "rook-ceph-osd-0" is down but no node drain is detected
2022-03-05 02:05:51.534749 E | ceph-crashcollector-controller: node reconcile failed on op "unchanged": Operation cannot be fulfilled on deployments.apps "rook-ceph-crashcollector-k5": the object has been modified; please apply your changes to the latest version and try again
2022-03-05 02:05:52.037192 I | op-osd: finished running OSDs in namespace "rook-ceph"
2022-03-05 02:05:52.037221 I | ceph-cluster-controller: done reconciling ceph cluster in namespace "rook-ceph"
2022-03-05 02:05:52.123944 I | ceph-cluster-controller: enabling ceph mon monitoring goroutine for cluster "rook-ceph"
2022-03-05 02:05:52.124027 I | op-osd: ceph osd status in namespace "rook-ceph" check interval "1m0s"
2022-03-05 02:05:52.124046 I | ceph-cluster-controller: enabling ceph osd monitoring goroutine for cluster "rook-ceph"
2022-03-05 02:05:52.124525 I | ceph-cluster-controller: ceph status check interval is 1m0s
2022-03-05 02:05:52.124555 I | ceph-cluster-controller: enabling ceph status monitoring goroutine for cluster "rook-ceph"
2022-03-05 02:05:53.037307 I | op-mgr: setting ceph dashboard "admin" login creds
2022-03-05 02:05:56.026944 I | clusterdisruption-controller: osd is down in the failure domain "k4", but pgs are active+clean. Requeuing in case pg status is not updated yet...
2022-03-05 02:05:57.647613 I | op-mgr: successfully set ceph dashboard creds
2022-03-05 02:06:00.028374 I | ceph-cluster-controller: Disabling the insecure global ID as no legacy clients are currently connected. If you still require the insecure connections, see the CVE to suppress the health warning and re-enable the insecure connections. https://docs.ceph.com/en/latest/security/CVE-2021-20288/
2022-03-05 02:06:00.028437 I | op-config: setting "mon"="auth_allow_insecure_global_id_reclaim"="false" option to the mon configuration database
2022-03-05 02:06:02.331488 I | clusterdisruption-controller: osd "rook-ceph-osd-2" is down but no node drain is detected
2022-03-05 02:06:02.331907 I | clusterdisruption-controller: osd "rook-ceph-osd-1" is down but no node drain is detected
2022-03-05 02:06:02.332545 I | clusterdisruption-controller: osd "rook-ceph-osd-0" is down but no node drain is detected
2022-03-05 02:06:02.435767 I | op-config: successfully set "mon"="auth_allow_insecure_global_id_reclaim"="false" option to the mon configuration database
2022-03-05 02:06:02.435796 I | ceph-cluster-controller: insecure global ID is now disabled
2022-03-05 02:06:05.038744 I | op-config: setting "mgr.a"="mgr/dashboard/server_port"="8443" option to the mon configuration database
2022-03-05 02:06:05.443498 I | clusterdisruption-controller: osd is down in the failure domain "k4", but pgs are active+clean. Requeuing in case pg status is not updated yet...
2022-03-05 02:06:05.840611 I | op-mon: parsing mon endpoints: c=10.103.231.110:6789,a=10.105.8.75:6789,b=10.109.89.77:6789
2022-03-05 02:06:05.933927 I | op-mon: parsing mon endpoints: c=10.103.231.110:6789,a=10.105.8.75:6789,b=10.109.89.77:6789
2022-03-05 02:06:05.934054 I | ceph-spec: detecting the ceph image version for image quay.io/ceph/ceph:v16.2.7...
2022-03-05 02:06:06.037445 I | op-mon: parsing mon endpoints: c=10.103.231.110:6789,a=10.105.8.75:6789,b=10.109.89.77:6789
2022-03-05 02:06:06.037521 I | ceph-spec: detecting the ceph image version for image quay.io/ceph/ceph:v16.2.7...
2022-03-05 02:06:06.329866 I | clusterdisruption-controller: osd "rook-ceph-osd-2" is down but no node drain is detected
2022-03-05 02:06:06.330233 I | clusterdisruption-controller: osd "rook-ceph-osd-1" is down but no node drain is detected
2022-03-05 02:06:08.332949 I | op-config: successfully set "mgr.a"="mgr/dashboard/server_port"="8443" option to the mon configuration database
2022-03-05 02:06:08.623384 I | ceph-spec: detected ceph image version: "16.2.7-0 pacific"
2022-03-05 02:06:08.623924 I | ceph-spec: detected ceph image version: "16.2.7-0 pacific"
2022-03-05 02:06:11.929119 I | ceph-block-pool-controller: creating pool "ceph-blockpool" in namespace "rook-ceph"
2022-03-05 02:06:17.026472 I | clusterdisruption-controller: osd is down in the failure domain "k5", but pgs are active+clean. Requeuing in case pg status is not updated yet...
2022-03-05 02:06:18.823160 I | op-mgr: dashboard config has changed. restarting the dashboard module
2022-03-05 02:06:18.823343 I | op-mgr: restarting the mgr module
2022-03-05 02:06:31.923601 I | ceph-file-controller: start running mdses for filesystem "ceph-filesystem"
2022-03-05 02:06:41.023288 I | cephclient: getting or creating ceph auth key "mds.ceph-filesystem-a"
2022-03-05 02:06:41.725066 I | ceph-object-controller: reconciling object store deployments
2022-03-05 02:06:41.823571 I | ceph-object-controller: ceph object store gateway service running at 10.110.222.53
2022-03-05 02:06:41.823724 I | ceph-object-controller: reconciling object store pools
2022-03-05 02:06:42.223504 I | op-mgr: successful modules: dashboard
2022-03-05 02:06:47.133594 I | op-mon: checking if multiple mons are on the same node
2022-03-05 02:06:48.923258 I | op-mds: setting mds config flags
2022-03-05 02:06:48.923383 I | op-config: setting "mds.ceph-filesystem-a"="mds_join_fs"="ceph-filesystem" option to the mon configuration database
2022-03-05 02:06:54.132780 I | op-config: successfully set "mds.ceph-filesystem-a"="mds_join_fs"="ceph-filesystem" option to the mon configuration database
2022-03-05 02:06:54.225769 I | cephclient: getting or creating ceph auth key "mds.ceph-filesystem-b"
2022-03-05 02:06:54.425026 E | ceph-crashcollector-controller: node reconcile failed on op "unchanged": Operation cannot be fulfilled on deployments.apps "rook-ceph-crashcollector-k5": the object has been modified; please apply your changes to the latest version and try again
2022-03-05 02:06:57.623115 I | cephclient: reconciling replicated pool ceph-blockpool succeeded
2022-03-05 02:06:58.723242 E | ceph-crashcollector-controller: node reconcile failed on op "unchanged": Operation cannot be fulfilled on deployments.apps "rook-ceph-crashcollector-k5": the object has been modified; please apply your changes to the latest version and try again
2022-03-05 02:07:04.523450 I | op-mds: setting mds config flags
2022-03-05 02:07:04.523509 I | op-config: setting "mds.ceph-filesystem-b"="mds_join_fs"="ceph-filesystem" option to the mon configuration database
2022-03-05 02:07:13.923101 I | op-config: successfully set "mds.ceph-filesystem-b"="mds_join_fs"="ceph-filesystem" option to the mon configuration database
2022-03-05 02:07:15.023486 I | ceph-block-pool-controller: initializing pool "ceph-blockpool"
2022-03-05 02:07:18.633307 I | ceph-block-pool-controller: successfully initialized pool "ceph-blockpool"
2022-03-05 02:07:18.633652 I | op-config: deleting "mgr/prometheus/rbd_stats_pools" option from the mon configuration database
2022-03-05 02:07:25.430237 I | op-config: successfully deleted "mgr/prometheus/rbd_stats_pools" option from the mon configuration database
2022-03-05 02:07:26.023574 I | cephclient: reconciling replicated pool ceph-objectstore.rgw.control succeeded
2022-03-05 02:07:31.849658 I | ceph-file-controller: creating filesystem "ceph-filesystem"
2022-03-05 02:07:35.931604 I | cephclient: setting pool property "pg_num_min" to "8" on pool "ceph-objectstore.rgw.control"
2022-03-05 02:07:43.030696 I | cephclient: reconciling replicated pool ceph-filesystem-metadata succeeded
2022-03-05 02:07:51.423075 I | cephclient: reconciling replicated pool ceph-filesystem-data0 succeeded
2022-03-05 02:07:54.525970 I | cephclient: reconciling replicated pool ceph-objectstore.rgw.meta succeeded
2022-03-05 02:07:55.423108 I | cephclient: creating filesystem "ceph-filesystem" with metadata pool "ceph-filesystem-metadata" and data pools [ceph-filesystem-data0]
2022-03-05 02:07:59.630446 I | cephclient: setting pool property "pg_num_min" to "8" on pool "ceph-objectstore.rgw.meta"
2022-03-05 02:08:01.931448 I | ceph-file-controller: created filesystem "ceph-filesystem" on 1 data pool(s) and metadata pool "ceph-filesystem-metadata"
2022-03-05 02:08:01.931478 I | cephclient: setting allow_standby_replay for filesystem "ceph-filesystem"
2022-03-05 02:08:14.911833 I | cephclient: reconciling replicated pool ceph-objectstore.rgw.log succeeded
2022-03-05 02:08:17.135036 I | cephclient: setting pool property "pg_num_min" to "8" on pool "ceph-objectstore.rgw.log"
2022-03-05 02:08:32.942945 I | cephclient: reconciling replicated pool ceph-objectstore.rgw.buckets.index succeeded
2022-03-05 02:08:35.060385 I | cephclient: setting pool property "pg_num_min" to "8" on pool "ceph-objectstore.rgw.buckets.index"

(base) joonwookim@Joonwooui-MacBookPro ~ % kubectl -n rook-ceph get pod
NAME                                                READY   STATUS      RESTARTS   AGE
csi-cephfsplugin-7dfcd                              3/3     Running     0          7m35s
csi-cephfsplugin-88m29                              3/3     Running     0          7m35s
csi-cephfsplugin-lg5bk                              3/3     Running     0          7m35s
csi-cephfsplugin-provisioner-5dc9cbcc87-npjrw       6/6     Running     0          7m35s
csi-cephfsplugin-provisioner-5dc9cbcc87-pk7dp       6/6     Running     0          7m35s
csi-rbdplugin-jnb5b                                 3/3     Running     0          7m36s
csi-rbdplugin-l768k                                 3/3     Running     0          7m36s
csi-rbdplugin-provisioner-58f584754c-gzmm4          6/6     Running     0          7m36s
csi-rbdplugin-provisioner-58f584754c-w224q          6/6     Running     0          7m36s
csi-rbdplugin-sk8c8                                 3/3     Running     0          7m36s
rook-ceph-crashcollector-k4-67d694c8-rvfz9          1/1     Running     0          5m51s
rook-ceph-crashcollector-k5-5c5f7d4969-2hlzv        1/1     Running     0          4m17s
rook-ceph-crashcollector-k6-75b6b99d64-h62cr        1/1     Running     0          5m37s
rook-ceph-mds-ceph-filesystem-a-67b9bbc648-dzd25    1/1     Running     0          4m17s
rook-ceph-mds-ceph-filesystem-b-99d9f9f6d-c584t     1/1     Running     0          3m58s
rook-ceph-mgr-a-579d76b94-jnjjr                     1/1     Running     0          5m59s
rook-ceph-mon-a-5966c66bb4-zqrpv                    1/1     Running     0          7m38s
rook-ceph-mon-b-5d97b4d79f-bkfsh                    1/1     Running     0          6m36s
rook-ceph-mon-c-6ffdbfdb6c-q26vb                    1/1     Running     0          6m21s
rook-ceph-operator-7bc8964f4d-4ttgh                 1/1     Running     0          13m
rook-ceph-osd-0-5b575bc997-w6gxf                    1/1     Running     0          5m26s
rook-ceph-osd-1-9cfb4f647-rslz7                     1/1     Running     0          5m25s
rook-ceph-osd-2-849d79dc98-jwknq                    1/1     Running     0          5m25s
rook-ceph-osd-prepare-k4-sqlqq                      0/1     Completed   0          5m38s
rook-ceph-osd-prepare-k5-qxf6b                      0/1     Completed   0          5m37s
rook-ceph-osd-prepare-k6-kt9wj                      0/1     Completed   0          5m37s
rook-ceph-rgw-ceph-objectstore-a-86cbd4d888-c2srq   1/1     Running     0          104s
rook-ceph-tools-7d94694498-nz664                    1/1     Running     0          7m46s
